Portata

500 kg

Altezza max. di lavoro

19 m

N. massimo occupanti

2/0

ES1912E

Portata

500 kg

Altezza max. di lavoro

19 m

N. massimo occupanti

2/0

Technische Daten

Electric-powered model with a robust and manageable structure. The electric scissor lift system allows for energy savings, ensuring zero emissions and silent operation, ideal for use inside buildings. The compact design and contained dimensions allow access through standard doors, guaranteeing maximum flexibility.

Technisches Datenblatt

• Automatic pothole protection system
• Crushing protection
• High ground clearance
• Self-locking door on the platform
• Speed limit at maximum height
• Drivable at full height
• Platform load sense system
• Automatic braking system
• Emergency brake release
• Non-marking tyres
• Tilt indicator with alarm
• Warning siren during lowering and dual flashing LED light
• Safety bracket for maintenance operations
• Horn
• Cylinder locking valve
• Emergency stop button
• Emergency lowering
• Traction engine protection
• Anchoring eyebolts
• Onboard diagnostics system
• Hour counter
• Proportional controls
• Fold-down guardrails
• Power to platform
• Maintenance free battery
• Explosion-proof tubing system
• Motion Alarm
• Charging protection system
• Charging indicator
• Tie-down and lifting points
• One way platform extension deck
• Two-wheel steering
• Two-wheel drive
• Self-weight lowering system
• Emergency pump

Normative

EN 280-1

ANSI/SAIA A92.20

Technische Daten

Caratteristica
StabilizzatoriNo-
Portata500 kg-
Portata estesa500 kg-
N. max di occupanti (interno/esterno)2/02/0
Altezza max. di lavoro19 m-
Altezza piano della piattaforma17 m-
Lunghezza Totale3.76 m-
Larghezza Totale1.25 m-
Altezza totale (parapetto sù)3.24 m-
Altezza di trasporto (parapetto giù)2.46 m-
Lunghezza della piattaforma3.44 m-
Larghezza della piattaforma1.17 m-
Estensione della piattaforma1.2 m-
Luce libera dal suolo (chiusa)15 m-
Luce libera dal suolo (aperta)0.25 m-
Passo2.89 m-
Raggio di sterzata (interno)1 m-
Raggio di sterzata (esterno)3.5 m-
Motori di guida2×32VAC/3.3 kW2×32VAC/3.3 kW
Motori di sollevamento48VDC/12.0 kW48VDC/12.0 kW
Velocità di traslazione (chiusa)4.5 km/h-
Velocità di traslazione (aperta)0.4 km/h-
Batterie48V/360Ah48V/360Ah
Caricabatterie integrato48V/60A48V/60A
Pendenza superabile30%30%
Pendenza di lavoro max.X-1,5°/Y-3°X-1,5°/Y-3°
Pneumatici antitraccia22x9x1622x9x16
Peso7140 kg-
