Load capacity

200 kg

Max. working height

11,2 m

Max. occupants

2/1

MJP11.5AC

Load capacity

200 kg

Working height

44 m

Max. occupants

2/1

Battery-powered self-propelled vertical platform. It has a lightweight but robust structure for working in total safety. The 345° turret rotation is the optimal solution for working in both indoor and outdoor spaces. The boom inclination is very useful for maintenance in indoor spaces.

• Proportional controls
• automatic undercarriage protection
• self-locking door on the platform
• Drive allowed at maximum height
• Platform horizontal outreach
• non-marking tires
• 2WD
• 2 steering wheels
• Automatic braking system
• Emergency descent system
• Emergency stop button
• Cylinder lock valve
• On-board diagnostic system
• Tilt sensor with alarm
• Motion alarm sensors
• Horn
• Hour meter
• Charger protection
• Flashing beacon
• Openable covers for easy maintenance
• 345° turret rotation
• 3 m horizontal extension
• Anti-burst hose system
• Platform load control system
• Drive enable system
• Charge indicator
• Manual brake release
• Anchoring and lifting points

Regulations

EN 280-1 Standards for mobile elevating work platforms (if available)

ANSI/SAIA A92.20

Technical Data

CaratteristicaMetricoImperiale
StabilizersNo-
Load capacity200 kg-
Max no. occupants2/12/1
Max. working height11.2 m-
Max platform height9.2 m-
Maximum horizontal reach3 m-
Up and over height7.89 m-
Overall length2.62 m97''
Overall width1 m-
Overall height1.99 m-
Platform length0.69 m22' 97''
Platform width (tyres)0.87 m-
Ground clearance (stowed)0.07 m-
Ground clearance (raised)0.02 m-
Wheelbase1.22 m-
Turning radius (inside)0 m-
Turning radius (outside)1.80 m-
Turret rotation345 °345 °
Jib movement+70°/-60°+70°/-60°
Driving motors24 V / 1,5 kW24 V / 1,5 kW
Lifting motor24 V / 3 kW24 V / 3 kW
Travel speed (stowed)4.5 km/h-
Travel speed (rated)0.5 km/h-
Up\Down Speed95 / 50 sec95 / 50 sec
Batteries24 V / 240 Ah24 V / 240 Ah
Integrated battery charger24 V / 30 A24 V / 30 A
Gradeability25%25%
Maximum working slope (indoor use)2,5° / 2,5°2,5° / 2,5°
Non-marking tyres381x127 mm381x127 mm
Weight2950 kg-
